| specification | Description |
|---|---|
| Frame | Haibike, AllMtn PW-X3, aluminum, Boost 12x148 mm, postmount |
| Fork | RockShox Yari RC, air, 160 mm travel |
| mute | RockShox Deluxe Select Plus, air, 160 mm travel |
| tax rate | Acros, BlockLock, aluminum |
| Stem | Haibike Components, TheStem, 31.8 mm |
| Handlebars | Haibike Components, TheBar, 31.8 x 780 mm |
| Grips / handlebar tape | Haibike MTB |
| Shift lever | Shimano Deore SLX M7100, 12-speed |
| Brake lever | Magura MT5 HC lever, aluminum |
| Rear derailleur | Shimano SLX M7100, 12-speed |
| crankset | Haibike Components, The Crank ++, aluminum, chainring with 36 teeth |
| cassette | Shimano M6100, 10-51 teeth |
| Chain | Shimano M6100 |
| Chain guide | Nylon direct mount |
| Brakes | Magura MT5 |
| Brake discs | Magura, 203mm |
| saddle | Selle Royal Vivo |
| Seat post | Dropper-Post Remote, Telescope, Aluminum, 34.9 mm |
| Seat post clamp | Hexagon socket, 38.1 mm |
| engine | Yamaha PW-X3, 250 Wh, 85 Nm |
| battery pack | Yamaha InTube, 750 Wh |
| Display/Remote | Yamaha Interface - X |
| charger | Fast Charger 4A |
| Wheel size | 29'' / 27.5'' |
| rims | WTB, ST i30 TCS, hollow chamber / WTB, ST i35 TCS, hollow chamber |
| VR hub / HR hub | Haibike Components, TheHub, thru axle 15x110mm, 6-hole / Haibike Components, TheHub, thru axle 12x148 mm, 6-hole |
| spokes | Sapim Race |
| Front/rear tires | Maxxis, Minion DHF II, 29 x 2.50 / Maxxis, Minion DHR II, 27.5 x 2.60 |
| Hoses / sealing milk | Sclaverand valve |
| Pedals | Freeride pedal, aluminum, with reflector |
| Maximum permissible total weight | 120.0kg |
